Hikvision

Hikvision DS-2CD2125G0-IMS — 2 MP HDMI Fixed Dome Network Camera

Manufacturer
Hikvision
Manufacturer part number
DS-2CD2125G0-IMS
BPC product number
BP-HIKVISION-4128754b3f06be7e1cd37aa1
Procurement help877-327-6106
Hikvision DS-2CD2125G0-IMS — 2 MP HDMI Fixed Dome Network Camera
Tech overview

High quality imaging with 2 MP resolution · Excellent low-light performance via powered-by-DarkFighter technology · Efficient H.265+ compression technology

Camera — Image Sensor
1/2.8" Progressive Scan CMOS
Camera — Min. Illumination
Color: 0.009 Lux @ (F1.6, AGC ON), 0 Lux with IR
Camera — Shutter Speed
1/3 s to 1/100,000 s
Camera — Slow Shutter
Yes
Camera — Wide Dynamic Range
120dB
Camera — Day & Night
IR Cut Filter
View full product specifications →
Overview

Built for the work ahead.

Product details

  • High quality imaging with 2 MP resolution
  • Excellent low-light performance via powered-by-DarkFighter technology
  • Efficient H.265+ compression technology
  • Clear imaging against strong back light due to 120 dB true WDR technology
  • Direct HD live view with HDMI output
  • Vandal proof (IK10)
  • Robust structure design with full metal materials.

Configuration: Model: DS-2CD2125G0-IMS. Configuration, compatible accessories and availability are confirmed in your quote.

Technical details

Product specifications

Specifications describe the listed configuration. We verify the exact manufacturer part number in your written quote.

Manufacturer
Hikvision
Manufacturer part number
DS-2CD2125G0-IMS
BPC product number
BP-HIKVISION-4128754b3f06be7e1cd37aa1
Camera — Image Sensor
1/2.8" Progressive Scan CMOS
Camera — Min. Illumination
Color: 0.009 Lux @ (F1.6, AGC ON), 0 Lux with IR
Camera — Shutter Speed
1/3 s to 1/100,000 s
Camera — Slow Shutter
Yes
Camera — Wide Dynamic Range
120dB
Camera — Day & Night
IR Cut Filter
Camera — Angle Adjustment
Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355°
Lens — Lens Type
2.8/4/6 mm
Lens — FOV
2.8 mm, horizontal FOV: 108°, vertical FOV: 58°, diagonal FOV: 128° ;4 mm, horizontal FOV: 86°, vertical FOV: 46°, diagonal FOV: 103° ;6 mm, horizontal FOV: 52° , vertical FOV: 29° , diagonal FOV: 60°
Lens — Aperture
F1.6
Lens — Lens Mount
Φ12
Illuminator — IR Range
Up to 30 m
Illuminator — Wavelength
850nm
Video — Max. Resolution
1920 × 1080
Video — Main Stream
50Hz: 50fps (1920 × 1080, 1280 × 720) ;60Hz: 60fps (1920 × 1080, 1280 × 720)
Video — Sub Stream
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) ;60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Video — Video Compression
Main stream: H.265/H.264,Sub-stream: H.265/H.264/MJPEG,Third stream: H.265/H.264
Video — Video Bit Rate
32 Kbps to 16 Mbps
Video — H.264 Type
Main Profile/High Profile
Video — H.265 Type
Main Profile
Video — H.264+
No
Video — H.265+
No
Video — Scalable Video Coding (SVC)
H.264 and H.265 encoding support
Video — Region of Interest (ROI)
Support 1 fixed region for main stream and sub-stream
Audio — Environment Noise Filtering
Yes
Audio — Audio Sampling Rate
8kHz/16kHz/32kHz/44.1kHZ/48kHz
Audio — Audio Compression
G.711/G.722.1/G.726/MP2L2/PCM
Audio — Audio Bit Rate
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)
Network — Simultaneous Live View
Up to 6 channels
Network — API
ONVIF (PROFILE S, PROFILE G), ISAPI
Network — Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour, WebSocket, WebSockets
Network — User/Host
Up to 32 users ,3 levels: Administrator, Operator and User
Network — Network Storage
microSD/SDHC/SDXC card (128 GB), local storage and NAS (NFS,SMB/CIFS), ANR; Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Network — Client
iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500
Network — Web Browser
Plug-in required live view: IE8+, Chrome 41.0-44, Firefox 30.0-51, Safari 8.0-11,Plug-in free live view: Chrome 45.0+, Firefox 52.0+
Network — Alarm Trigger
Motion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD full, HDD error
Image — Day/Night Switch
Day/Night/Auto/Schedule/Triggered by Alarm In
Image — DNR
3D DNR
Image — Image Enhancement
BLC/3D DNR/HLC
Image — Image Settings
Saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser
Interface — Audio
1 input (line in/mic in, terminal block), 1 output ( two-core terminal block), mono sound
Interface — Alarm
1 input, 1 output (max. 12 VDC, 30 mA), terminal block
Interface — Video Output
1 HDMI™, type D, female plug (-M)
Interface — On-board Storage
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
Interface — Hardware Reset
Yes
Interface — Communication Interface
1 RJ45 10M/100M self-adaptive Ethernet port
Event — Smart Event
Line crossing detection, intrusion detection
Event — Face Detection
Yes
General — General Function
Anti-flicke, heartbeat, mirror, privacy masks, password reset via e-mail, pixel counter, HTTP listening
General — Startup and Operating Conditions
IR on: -10 °C to 40 °C (14 °F to 104 °F), humidity 95% or less (non-condensing) ; IR off: -10 °C to 50 °C (14 °F to 122 °F), humidity 95% or less (non-condensing)
General — Power Supply
12 VDC ± 25%, Φ 5.5 mm coaxial power plug,PoE (802.3af, class 3)
General — Power Consumption and Current
12 VDC, 0.6 A, max. 7 W; PoE (802.3af, 36 V to 57 V), 0.3 A to 0.2 A, max. 8. 5W
General — Camera Dimension
Camera: Φ 119 × 90 mm (Φ 4.7" × 3.5")
General — Camera Weight
Camera: Approx. 520 g (1.1 lb.) With package: Approx. 750 g (1.7 lb.)
Approval — Protection
IK10
Condition
New
Exact configuration
Model: DS-2CD2125G0-IMS. Configuration, compatible accessories and availability are confirmed in your quote.
