Description
Product details
- High quality imaging with 4 MP resolution
- Efficient H.265+ compression technology
- Clear imaging against strong back light due to 130 dB WDR technology
- 24/7 colorful imaging
- Focus on human and vehicle targets classification based on deep learning
- -SU: Built-in microphone for real-time audio security, audio and alarm interface available
- Water and dust resistant (IP67) and vandal resistant (IK10)
Configuration: Model: DS-2CD2147G2(-SU). Configuration, compatible accessories and availability are confirmed in your quote.
Specifications
| Camera — Image Sensor | 1/1.8" Progressive Scan CMOS |
|---|---|
| Camera — Max. Resolution | 2688 × 1520 |
| Camera — Min. Illumination | 0.0005 Lux @ (F1.0, AGC ON) |
| Camera — Shutter Time | 1/3 s to 1/100,000 s |
| Camera — Day & Night | Blue glass module to reduce ghost phenomenon |
| Camera — Angle Adjustment | Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355° |
| Lens — Lens Type | Fixed focal lens, 2.8 and 4 mm optional |
| Lens — Focal Length & FOV | 2.8 mm, horizontal FOV 112°, vertical FOV 61°, diagonal FOV 134° 4 mm, horizontal FOV 95°, vertical FOV 51°, diagonal FOV 115° |
| Lens — Lens Mount | M16 |
| Lens — Iris Type | Fixed |
| Lens — Aperture | F1.0 |
| Pixel Density — DORI | 2.8 mm, D: 58 m, O: 23 m, R: 11 m, I: 2 m 4 mm, D: 77 m, O: 30 m, R: 15 m, I: 7 m |
| Video — Main Stream | 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720) |
| Video — Sub-Stream | 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) |
| Video — Third Stream | 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) *Third stream is supported under certain settings. |
| Video — Video Compression | Main stream: H.265/H.264/H.265+/H.264+ Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264 *Third stream is supported under certain settings. |
| Video — Video Bit Rate | 32 Kbps to 8 Mbps |
| Video — H.264 Type | Baseline Profile/Main Profile/High Profile |
| Video — H.265 Type | Main Profile |
| Video — Bit Rate Control | CBR/VBR |
| Video — Scalable Video Coding (SVC) | H.264 and H.265 encoding |
| Video — Region of Interest (ROI) | 1 fixed region for main stream and sub-stream |
| Audio — Audio Compression | -SU: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
| Audio — Audio Bit Rate | -SU: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) |
| Audio — Audio Sampling Rate | -SU: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Audio — Environment Noise Filtering | -SU: Yes |
| Network — Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket, WebSockets |
| Network — Simultaneous Live View | Up to 6 channels |
| Network — API | Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK |
| Network — User/Host | Up to 32 users. 3 user levels: administrator, operator and user |
| Network — Security | Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface |
| Network — Network Storage | MicroSD/microSDHC/microSDXC card (512 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR) Together with high-end Hikvision memory card, memory card encryption and health detection are supported. |
| Network — Client | iVMS-4200, Hik-Connect, Hik-Central |
| Network — Web Browser | Plug-in required live view: IE 10, IE 11 Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+ Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+ |
| Image — Image Parameters Switch | Yes |
| Image — Image Settings | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser |
| Image — Wide Dynamic Range (WDR) | 130 dB |
| Image — SNR | ≥ 52 dB |
| Image — Image Enhancement | BLC, HLC, 3D DNR |
| Interface — Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
| Interface — On-Board Storage | Built-in memory card slot, support microSD/SDHC/SDXC/TF card, up to 512 GB |
| Interface — Built-in Microphone | -SU: Yes |
| Interface — Audio | -SU: 1 input (line in), max. input amplitude: 3.3 vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium; 1 output (line out), max. output amplitude: 3.3 vpp, output impedance: 100 Ω, interface type: non-equilibrium, mono sound |
| Interface — Alarm | -SU: 1 input, 1 output (max. 12 VDC, 30 mA) |
| Interface — Reset Key | Yes |
| Event — Basic Event | Motion detection (human and vehicle targets classification), video tampering alarm, exception |
| Event — Smart Event | Line crossing detection, intrusion detection, region entrance detection, region exiting detection Scene change detection |
| Event — Linkage | Upload to FTP/memory card/NAS, notify surveillance center, trigger recording, trigger capture, send email -SU: audible warning |
| Deep Learning Function — Face Capture | Yes |
| General — Power | 12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5 mm coaxial power plug PoE: 802.3af, Class 3, 36 V to 57 V, 0.20 A to 0.15 A, max. 6.5 W |
| General — Dimension | Ø121.4 mm × 100.1 mm (Ø4.8" × 3.9") |
| General — Package Dimension | 150 mm × 150 mm × 141 mm (5.9" × 5.9" ×5.6") |
| General — Weight | Approx. 580 g (1.2 lb.) |
| General — With Package Weight | Approx. 820 g (1.6 lb.) |
| General — Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| General — Startup and Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| General — Language | 33 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| General — General Function | Anti-flicker, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter |
| Approval — EMC | FCC SDoC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC VoC (ICES-003: Issue 6, 2016) |
| Approval — Safety | UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014) |
| Approval — Environment | CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
| Approval — Protection | IP67 (IEC 60529-2013), IK10 (IEC 62262:2002) |
Request a quote to confirm availability, compatibility, warranty coverage, shipping and deployment services for your project.
