Description
Product details
- Intel Core Ultra 7 255HX, 20C (8P + 12E) / 20T, Max Turbo up to 5.2GHz, 30MB Intel Smart Cache
- 64 GB RAM
- 2 TB SSD
- Windows 11 Pro
Configuration: Intel Core Ultra 7 255HX, 20C (8P + 12E) / 20T, Max Turbo up to 5.2GHz, 30MB Intel Smart Cache | 64 GB RAM | 2 TB SSD | Windows 11 Pro
Specifications
| Processor | Intel Core Ultra 7 255HX, 20C (8P + 12E) / 20T, Max Turbo up to 5.2GHz, 30MB Intel Smart Cache |
|---|---|
| Memory | 64 GB |
| Memory configuration | 2x 32GB SODIMM DDR5-5600 Non-ECC |
| Internal Storage | 2 TB |
| Storage type | SSD |
| Operating system | Windows 11 Pro |
| AI PC Category | AI PC |
| NPU | Integrated Intel AI Boost, up to 13 TOPS |
| Graphics | NVIDIA GeForce RTX 5090 24GB GDDR7 Laptop GPU |
| Chipset | Intel WM880 Chipset |
| Memory Slots | Four DDR5 SODIMM / CSODIMM slots, dual-channel capable |
| Max Memory | Models with Non-ECC memory: Up to 192GB (4x 48GB SODIMM DDR5-5600 Non-ECC / CSODIMM DDR5-6400 Non-ECC ); Models with ECC memory: Up to 128GB (4x 32GB SODIMM DDR5-5600 ECC) |
| Storage | 2TB SSD M.2 2280 PCIe 5.0×4 Performance NVMe Opal 2.0 |
| Storage Slot | Three M.2 slots • One M.2 2280 PCIe 5.0 x4 slot • Two M.2 2280 PCIe 4.0 x4 slots |
| Max Storage Support | Up to three M.2 2280 Gen 5 Performance SSD; up to 12TB, 4TB each |
| RAID Preset | None |
| Card Reader | SD Express 8.0 Card Reader |
| Audio Chip | SoundWire, Cirrus Logic CS42L43 codec |
| Speakers | Stereo speakers, 2W x2, Dolby Atmos |
| Microphone | 2x, Array |
| Camera | 5.0MP + IR with Privacy Shutter and Computer Vision Human Presence Detection on ISP |
| Battery | 99.9Wh |
| Power Adapter | 180W USB-C GaN (3-pin) |
| Display | 16" 3.2K (3200×2000) Tandem OLED 600nits Anti-glare / Anti-reflection / Anti-smudge, 100% DCI-P3, 40-120Hz, DisplayHDR 600, Dolby Vision, Eyesafe, TÜV Low Blue Light, Touch |
| Touchscreen | Add-on Film Touch, 10-point Multi-touch |
| Screen-to-Body Ratio | 82% |
| Color Calibration | X-Rite Factory Color Calibration |
| Pen | Pen Upgradable (Purchase Separately) |
| Keyboard | Backlit, English |
| Dimensions (WxDxH) | 362 x 252 x 15.8 / 20.9 (front / rear), 29.8 (maximum) mm 14.25 x 9.92 x 0.62 / 0.82 (front / rear), 1.17 (maximum) inches |
| Weight | Starting at 2.54 kg (5.6 lbs) |
| Case Color | Black |
| Case Material | Aluminium (Top), Aluminium (Bottom) |
| Bundled Software | Lenovo AI Now + ThinkShield Pro (SentinelOne, Sepio, Cigent) 1-year |
| WLAN + Bluetooth | Intel Wi-Fi 7 BE200, 802.11be 2×2 + BT5.4 |
| WWAN | WWAN Not Supported |
| SIM Card | No physical SIM card included |
| Ethernet | 1x 2.5GbE RJ-45 |
| NFC | No NFC |
| Standard Ports | 1x USB-A (USB 10Gbps / USB 3.2 Gen 2), Always On; 1x USB-A (USB 10Gbps / USB 3.2 Gen 2); 2x Thunderbolt 5, with DisplayPort 2.1 and USB PD 3.1, 180W input / 15W output; 1x Thunderbolt 4, with DisplayPort 2.1 and USB PD 3.1, 180W input / 15W output; 1x HDMI 2.1, up to 8K/60Hz; 1x Headphone / microphone combo jack (3.5mm); 1x Ethernet (2.5GbE RJ-45); 1x SD Express 8.0 card reader; 1x Kensington Nano Security Slot |
| Optional Ports (configured) | None |
| Docking | Various docking solutions supported via Thunderbolt / USB-C. For more compatible docking solutions, please visit Docking for ThinkPad P16 Gen 3 / T16g Gen 3 |
| Security Chip | Discrete TPM 2.0 Enabled |
| Physical Locks | Kensington Nano Security Slot, 2.5 x 6 mm |
| Smart Card Reader | No Smart Card Reader |
| Fingerprint Reader | Touch Style, Match-on-Chip, Integrated in Power Button |
| Other Security | Camera privacy shutter (camera models); Computer Vision-based User Presence Sensing on Image Signal Processor (ISP) |
| System Management | Non-vPro |
| Base Warranty | 1-year, Courier or Carry-in |
| Included Upgrade | 1Y Premier Support Upgrade from 1Y Courier/Carry-in |
| Bundled Accessories | None |
| Green Certifications | ENERGY STAR 9.0; EPEAT 2.0 Gold Registered; RoHS compliant; TCO Certified, generation 10 |
| Mil-Spec Test | MIL-STD-810H military test passed |
| Other Certifications | Eyesafe Certified 2.0; TÜV Rheinland Low Blue Light |
| Machine Type | 21V5 |
| TopSeller | TopSeller |
| EAN / UPC / JAN | 199273654611 |
| End of Support | 2032-04-09 |
| Announce Date | 2025-12-26 |
| Operating system details | Windows 11 Pro, English (US) / English (UK) |
Request a quote to confirm availability, compatibility, warranty coverage, shipping and deployment services for your project.
