Description
Product details
- AMD Ryzen 5 PRO 230 (6C / 12T, 3.5 / 4.9GHz, 6MB L2 / 16MB L3)
- 16 GB RAM
- 256 GB SSD
- Windows 11 Pro
Configuration: AMD Ryzen 5 PRO 230 (6C / 12T, 3.5 / 4.9GHz, 6MB L2 / 16MB L3) | 16 GB RAM | 256 GB SSD | Windows 11 Pro
Specifications
| Processor | AMD Ryzen 5 PRO 230 (6C / 12T, 3.5 / 4.9GHz, 6MB L2 / 16MB L3) |
|---|---|
| Memory | 16 GB |
| Memory configuration | 1x 16GB SODIMM DDR5-5600 |
| Internal Storage | 256 GB |
| Storage type | SSD |
| Operating system | Windows 11 Pro |
| AI PC Category | AI PC |
| NPU | Integrated AMD Ryzen AI, up to 16 TOPS |
| Graphics | Integrated AMD Radeon 760M Graphics |
| Chipset | AMD SoC Platform |
| Memory Slots | Two DDR5 SODIMM slots, dual-channel capable |
| Max Memory | Hawk Point: up to 64GB DDR5-5600 |
| Storage | 256GB SSD M.2 2280 PCIe 4.0×4 NVMe Opal 2.0 |
| Storage Slot | One M.2 2280 PCIe 4.0 x4 slot |
| Max Storage Support | Hawk Point: one drive, up to 1TB M.2 2280 SSD |
| Optical | None |
| Card Reader | No Card Reader |
| Audio Chip | High Definition (HD) Audio, Realtek ALC3287 codec |
| Speakers | Stereo speakers, 2W x2, Dolby Atmos |
| Microphone | 2x, 360° |
| Camera | 5.0MP + IR Discrete with Privacy Shutter |
| Battery | 75Wh |
| Power Adapter | 65W USB-C (2-pin) |
| Display | 14" WUXGA (1920×1200) IPS 400nits Anti-glare, 45% NTSC, 60Hz, DBEF5 |
| Touchscreen | None |
| Screen-to-Body Ratio | 87.49% |
| Pen | Pen Not Supported |
| Keyboard | Backlit, English |
| Dimensions (WxDxH) | 313.6 x 221.7 x 11.3/15.88 (front/rear), 21.95 (maximum) mm 12.35 x 8.73 x 0.44/0.63 (front/rear), 0.86 (maximum) inches |
| Weight | Starting at 1.32 kg (2.90 lbs) |
| Case Color | Black |
| Case Material | PC + 20% CF (Top), PC + 20% CF (Bottom) |
| Bundled Software | None |
| WLAN + Bluetooth | MediaTek Wi-Fi 7 MT7925, 802.11be 2×2 + BT5.4 |
| WWAN | WWAN Not Supported |
| SIM Card | No physical SIM card included |
| Ethernet | 100/1000M (RJ-45) |
| NFC | No NFC |
| Standard Ports | 1x USB-A (USB 5Gbps), Always On; 1x USB-A (USB 5Gbps); 2x Thunderbolt 4, with USB PD 15-100W and DisplayPort 2.1 (Gorgon Point) / DisplayPort 1.4a (Hawk Point); 1x HDMI 2.1, up to 4K/60Hz; 1x Headphone / microphone combo jack (3.5mm); 1x Ethernet (RJ-45) |
| Optional Ports (configured) | None |
| Docking | Various docking solutions supported via Thunderbolt / USB-C. For more compatible docking solutions, please visit Docking for ThinkPad T14 Gen 7 (AMD) |
| ThinkShield | ThinkShield is a comprehensive security solution that encompasses hardware, software, and supply chain components. For more details, visit here |
| Security Chip | Discrete TPM 2.0 Enabled |
| Physical Locks | Kensington Nano Security Slot, 2.5 x 6 mm |
| Smart Card Reader | No Smart Card Reader |
| Fingerprint Reader | Touch Style, Match-on-Chip, Integrated in Power Button |
| Other Security | Camera privacy shutter (camera models); IR camera for Windows Hello (facial recognition) |
| System Management | DASH |
| Base Warranty | 1-year, Courier or Carry-in |
| Included Upgrade | None |
| Bundled Accessories | None |
| Green Certifications | ENERGY STAR 9.0; EPEAT 2.0 Gold Registered; ErP Lot 6/26; RoHS compliant; TCO Certified, generation 10 |
| Mil-Spec Test | MIL-STD-810H military test passed |
| Other Certifications | – |
| Machine Type | 22AL |
| TopSeller | TopSeller |
| EAN / UPC / JAN | 199276580207 |
| End of Support | 2032-11-21 |
| Announce Date | 2026-05-05 |
| Operating system details | Windows 11 Pro, English (US) / English (UK) |
