Description
Product details
- AMD Ryzen 5 220 (6C / 12T, 3.2 / 4.9GHz, 6MB L2 / 16MB L3)
- 16 GB RAM
- 512 GB SSD
- Windows 11 Pro
Configuration: AMD Ryzen 5 220 (6C / 12T, 3.2 / 4.9GHz, 6MB L2 / 16MB L3) | 16 GB RAM | 512 GB SSD | Windows 11 Pro
Specifications
| Processor | AMD Ryzen 5 220 (6C / 12T, 3.2 / 4.9GHz, 6MB L2 / 16MB L3) |
|---|---|
| Memory | 16 GB |
| Memory configuration | 1x 16GB SODIMM DDR5-5600 |
| Internal Storage | 512 GB |
| Storage type | SSD |
| Operating system | Windows 11 Pro |
| AI PC Category | Non-AI PC |
| NPU | None |
| Graphics | Integrated AMD Radeon 740M Graphics |
| Chipset | AMD SoC Platform |
| Memory Slots | Two DDR5 SODIMM slots, dual-channel capable |
| Max Memory | Up to 64GB DDR5-5600 |
| Storage | 512GB SSD M.2 2242 PCIe 4.0×4 NVMe |
| Storage Slot | Two M.2 slots • One M.2 2242 PCIe 4.0 x4 slot • One M.2 2280 PCIe 4.0 x4 slot |
| Max Storage Support | Up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 2TB • M.2 2280 SSD up to 2TB |
| Card Reader | SD Card Reader |
| Audio Chip | High Definition (HD) Audio, Realtek ALC3287 codec |
| Speakers | Stereo speakers, 2W x2, Dolby Audio |
| Microphone | 2x, Array |
| Camera | FHD 1080p + IR Hybrid with Privacy Shutter |
| Battery | 48Wh |
| Power Adapter | 65W USB-C Slim (2-pin, Wall-mount) |
| Special Features | Modern Standby |
| Display | 14" WUXGA (1920×1200) IPS 400nits Anti-glare, 45% NTSC, 60Hz |
| Touchscreen | None |
| Screen-to-Body Ratio | 90% |
| Color Calibration | No Color Calibration |
| Pen | Pen Not Supported |
| Keyboard | Backlit, English |
| Touchpad | Buttonless Mylar surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches) |
| Dimensions (WxDxH) | 313.5 x 224 x 17.5 mm (12.34 x 8.82 x 0.69 inches) |
| Weight | Starting at 1.36 kg (2.99 lbs) |
| Case Color | Arctic Grey |
| Case Material | Aluminium (Top), PC-ABS (Bottom) |
| Surface Treatment | Anodizing Sandblasting (Top), Texture (Bottom) |
| Bundled Software | Office Trial |
| WLAN + Bluetooth | Wi-Fi 7, 802.11be 2×2 + BT5.4 |
| WWAN | WWAN Not Supported |
| Ethernet | 100/1000M (RJ-45) |
| Standard Ports | 1x USB-A (USB 5Gbps), Always On; 1x USB-A (USB 5Gbps); 2x USB-C (USB4 40Gbps), with USB PD 45-65W and DisplayPort 1.4a; 1x HDMI 2.1, up to 4K/60Hz; 1x Headphone / microphone combo jack (3.5mm); 1x Ethernet (RJ-45); 1x SD card reader |
| Docking | Various docking solutions supported via USB-C. For more compatible docking solutions, please visit Docking for ThinkBook 14 G9 AHP |
| Security Chip | Discrete TPM 2.0 Enabled |
| Physical Locks | Kensington Nano Security Slot, 2.5 x 6 mm |
| Fingerprint Reader | Touch Style, Match-on-Chip, Integrated in Power Button |
| Other Security | Camera privacy shutter; IR camera for Windows Hello (facial recognition) |
| Base Warranty | 1-year, Courier or Carry-in |
| Included Upgrade | None |
| Bundled Accessories | None |
| Green Certifications | ENERGY STAR 9.0; EPEAT 1.0 Gold Registered; ErP Lot 6/26; RoHS compliant; TCO Certified, generation 10 |
| Mil-Spec Test | MIL-STD-810H military test passed |
| Other Certifications | TÜV Rheinland Low Blue Light (Software Solution) |
| Machine Type | 21V0 |
| TopSeller | TopSeller |
| EAN / UPC / JAN | 199272125792 |
| End of Support | 2032-06-14 |
| Announce Date | 2025-12-05 |
| Operating system details | Windows 11 Pro, English (US) / English (UK) |
Request a quote to confirm availability, compatibility, warranty coverage, shipping and deployment services for your project.
