Description
Product details
- High quality imaging with 4 MP resolution
- Support Human and Vehicle Detection
- Smart Dual-Light: advanced technology with long range
- Built-in microphone for real-time audio security
- Water and dust resistant (IP67) and vandal resistant (IK08)
- Efficient H.265+ compression technology
- Support on-board storage up to 256 GB (SD card slot) (Optional)
Configuration: Model: DS-2CD1143G2-LIU(F)(/AB). Configuration, compatible accessories and availability are confirmed in your quote.
Specifications
| Camera — Image Sensor | 1/3" Progressive Scan CMOS |
|---|---|
| Camera — Max. Resolution | 2560 × 1440 |
| Camera — Min. Illumination | Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR |
| Camera — Shutter Time | 1/3 s to 1/100,000 s |
| Camera — Day & Night | IR cut filter |
| Camera — Angle Adjustment | Pan: 0° to 355°,tilt: 0° to 75°,rotate: 0° to 355° |
| Lens — Lens Type | Fixed focal lens, 2.8 and 4 mm optional |
| Lens — Focal Length & FOV | 2.8 mm, horizontal FOV 98°, vertical FOV 54°, diagonal FOV 114° 4 mm, horizontal FOV 78°, vertical FOV 42°, diagonal FOV 93° |
| Lens — Lens Mount | M12 |
| Lens — Iris Type | Fixed |
| Lens — Aperture | F1.6 |
| Pixel Density — DORI | 2.8 mm, D: 63 m, O: 25 m, R: 12 m, I: 6 m 4 mm, D: 78 m, O: 31 m, R: 15 m, I: 7 m |
| Illuminator — Supplement Light Type | IR,White Light |
| Illuminator — Supplement Light Range | Up to 30 m |
| Illuminator — Smart Supplement Light | Yes |
| Illuminator — IR Wavelength | 850 nm |
| Video — Main Stream | 50 Hz: 20 fps (2560 × 1440) 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 20 fps (2560 × 1440) 24 fps (1920 × 1080, 1280 × 720) |
| Video — Sub-Stream | 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 24 fps (1280 × 720, 640 × 480, 640 × 360) |
| Video — Video Compression | Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG |
| Video — Video Bit Rate | 32 Kbps to 8 Mbps |
| Video — H.264 Type | Baseline Profile,Main Profile,High Profile |
| Video — H.265 Type | Main Profile |
| Video — Bit Rate Control | CBR,VBR |
| Video — Region of Interest (ROI) | 1 fixed region for main stream |
| Audio — Audio Type | Mono sound |
| Audio — Environment Noise Filtering | Yes |
| Audio — Audio Sampling Rate | 8 kHz/16 kHz |
| Audio — Audio Compression | G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC |
| Audio — Audio Bit Rate | 64 Kbps (G.711 ulaw)/64 Kbps (G.711 alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC) |
| Network — Security | Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address) |
| Network — Simultaneous Live View | Up to 6 channels |
| Network — API | Open Network Video Interface (Profile S, Profile T, Profile G (only -F model supports)),ISAPI,SDK |
| Network — Protocols | TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP |
| Network — User/Host | Up to 32 users 3 user levels: administrator, operator, and user |
| Network — Client | iVMS-4200,Hik-Connect |
| Network — Web Browser | Plug-in required live view: IE 10, IE 11, Local service: Chrome 57.0+, Firefox 52.0+ |
| Image — Wide Dynamic Range (WDR) | 120 dB |
| Image — SNR | ≥ 52 dB |
| Image — Day/Night Switch | Day,Night,Auto,Schedule |
| Image — Image Enhancement | BLC,HLC,3D DNR |
| Image — Image Settings | Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser |
| Image — Privacy Mask | 4 programmable polygon privacy masks |
| Interface — Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
| Interface — On-Board Storage | -F: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB |
| Interface — Built-in Microphone | Yes |
| Interface — Reset Key | -F: Yes |
| Event — Basic Event | Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception |
| Event — Linkage | Upload to FTP/memory card (-F), send email, notify surveillance center, trigger recording (-F), trigger capture |
| General — Power | 12 VDC ± 25%, 0.5 A, max. 6 W,Ø5.5 mm coaxial power plug,reverse polarity protection, PoE: IEEE 802.3af, Class 3, max. 7.5 W |
| General — Material | Metal & Plastic |
| General — Dimension | Ø121.4 mm × 97.7 mm (Ø4.8" × 3.8") |
| General — Package Dimension | 150 mm × 150 mm × 141 mm (5.9" × 5.9" × 5.6") |
| General — Weight | Approx. 550 g (1.2 lb.) |
| General — With Package Weight | Approx. 800 g (1.8 lb.) |
| General — Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| General — Startup and Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| General — Language | English, Ukrainian |
| General — General Function | Heartbeat,anti-banding,mirror,password protection,password reset via email |
| Approval — EMC | FCC: 47 CFR Part 15, Subpart B, CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7 |
| Approval — Safety | UL: UL 62368-1, CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017, BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005 |
| Approval — Environment | CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006 |
| Approval — Protection | IP67: IEC 60529-2013,IK08: IEC 62262:2002 |
Request a quote to confirm availability, compatibility, warranty coverage, shipping and deployment services for your project.
